Home › Part 23414-120000

23414-120000 Marine + Industrial

GASKET, 12X1.0

23414-120000 — Affiliate Parts Search

AmazoneBayAliExpress

As an Amazon Associate I earn from qualifying purchases. Other links (eBay, AliExpress) are also affiliate links — they help pay for the site, at no extra cost to you. More

Fitted to

Engines, drives and generators whose parts catalogue lists this part. Open any for its exploded parts list.

Engines
3TN75E-G1 24hp3TN75E-G2 24hp3TN82E-G1 33hp3TN82E-G2 33hp3TN84L-RTBZ 33hp3TNE84-G1A3TNE84-G2A3TNE84-SA3TNE84C-G1A3TNE84T-EMP4TN82E-G1 38hp4TN82E-G2 38hp4TNE88-PG1GM 7.5hp1GM10 9hp1GM10C 9hp3GM30 27hp3GM30-YEU 27hp3GM30B 27hp3GM30C 27hp3GM30C-YEU 27hp3GM30F 27hp3GM30F-YEU 27hp3GM30FC-YEU 27hp3GM30FVE 27hp3GM30VE 27hp3HM35C 34hp3HM35F 34hp3JH2 38hp3JH2-TE 47hp3JH2Z 38hp3JH3CE 40hp3JH3E 40hp3JH3E(EPA) 40hp3JH40 40hp3QM 30hp4JH 44hp4JH-DTE 77hp4JH-HT 66hp4JH-HTE 75hp4JH-T 55hp4JH-TE 50hp4JH110 110hp4JH2-DTE 88hp4JH2-HTE 75hp4JH2-TE 62hp4JH2-UTE(B) 100hp4JH2E 50hp4JH3-DTE 125hp4JH3-HTE 100hp4JH3-TBE 75hp4JH3-TE 75hp4JH3CE 56hp4JH3CE1 56hp4JH3E 56hp4JH45 45hp4JH57 57hp4JH80 80hp4JHE 44hp4LH-DTE 170hp4LH-HTE 140hp4LH-STE 230hp4LHA-DTE(P) 200hp4LHA-DTZE(P) 200hp4LHA-HTE(P) 160hp4LHA-HTZE(P) 160hp4LHA-STE(P) 240hp4LHA-STZE(P) 240hp4LV150 150hp4LV170 170hp4LV195 195hp4LV230 230hp4LV250 250hp6LP-DTE 250hp6LP-DTZE 250hp6LP-DTZEP1 250hp6LP-STE 300hp6LP-STZE 300hp6LP-STZEP1 300hp6LPA-STP2 315hp6LPA-STZP2 315hp6LPA-STZP3 315hp

Supersession

Superseded by
Part No.DescriptionCodeApplies
22190-120002 WASHER, SEAL 12 N A=*2000.03; B=*2000.03; C=*2000.03; D=*2000.03; A=*2000.03; B=E/#A01028; C=*2000.03; A=*2017.11.; B=*2017.11.; A=E/#20635; B=E/#30557; A=E/#22733; B=E/#22733; C=E/#22733; D=E/#10829; E=*2000.03; F=*2000.03
Replaces (older)
Part No.DescriptionCodeApplies
104200-59170 GASKET, 12 N A=*1985.03; B=*1985.03; C=*1985.03; A=E01179; B=E11201

Aftermarket equivalents cross-ref

Third-party equivalents (Jabsco, Sierra, WIX, Mann…) — not OEM; verify before ordering. Usually cheaper than the marine dealer.

Equivalent P/NBrandDescriptionSourceConfidence
DIN 7603 12x1.0 DIN 7603 / Cu copper sealing washer ID 12 x 1.0mm - Yanmar 'GASKET; 12X1.0' = copper washer ID 12mm x 1.0mm thick; DIN 7603 mcmaster.com confirmed

Used in 91 places

Every catalog figure this part is placed in, the model(s) it applies to, and its reference/level/quantity.

Model(s)CatalogFigurePageRefLevQty
3TN75E-G1, 3TN75E-G2, 3TN82E-G1, 3TN82E-G2, 4TN82E-G1, 4TN82E-G2 3TN82E Parts Catalog Fig 27. FUEL STRAINER 43 45 1 2
3TN84L-RTBZ 3TN84L Parts Catalog Fig 14. FUEL OIL PIPES 19 30 1 2
3TNE84-G1A, 3TNE84-G2A, 3TNE84-SA, 3TNE84C-G1A 3TNE84 Parts Catalog Fig 15. FUEL INJECTION VALVE 25 73 1 2
3TNE84-G1A, 3TNE84-G2A, 3TNE84-SA, 3TNE84C-G1A 3TNE84 Parts Catalog Fig 22. GASKET SET 37 27 2 2
3TNE84T-EMP 3TNE84T-EMP Parts Catalog Fig 15. FUEL INJECTION VALVE (A)=3TNE84T-EMP 20 43 1 2
3TNE84T-EMP 3TNE84T-EMP Parts Catalog Fig 19. GASKET SET (A)=3TNE84T-EMP 24 24 2 2
4TNE88-PG 4TNE88-PG Parts Catalog Fig 14. FUEL INJECTION VALVE (A)=4TNE88-PG 19 44 1 2
4TNE88-PG 4TNE88-PG Parts Catalog Fig 18. GASKET SET (A)=4TNE88-PG 23 23 2 2
1GM 1GM 2GM 3GM 3HM Parts Catalog Fig 25. LUB. OIL PIPE 35 16 1 8
1GM 1GM 2GM 3GM 3HM Parts Catalog Fig 38. FUEL PIPE 50 37 1 6
1GM 1GM 2GM 3GM 3HM Parts Catalog Fig 65. GASKET KIT(OPTIONAL) 78 42 2 20
1GM 1GM 2GM 3GM 3HM Parts Catalog Fig 77. FUEL PIPE 92 28 1 6
1GM10, 1GM10C 1GM10 Parts Catalog Fig 29. LUB.OIL LINE 36 4 1 4
1GM10, 1GM10C 1GM10 Parts Catalog Fig 29. LUB.OIL LINE 36 9 1 4
1GM10, 1GM10C 1GM10 Parts Catalog Fig 42. FUEL LINE 49 20 1 2
1GM10, 1GM10C 1GM10 Parts Catalog Fig 42. FUEL LINE 49 21 1 4
1GM10 1GM10 Parts Catalog Fig 43. FUEL LINE 50 20 1 2
1GM10 1GM10 Parts Catalog Fig 43. FUEL LINE 50 21 1 4
1GM10, 1GM10C 1GM10 Parts Catalog Fig 85. GASKET SET(OPTIONAL) 92 14 2 20
3GM30, 3GM30-YEU, 3GM30C-YEU, 3GM30F-YEU, 3GM30FC-YEU 3GM30-YEU Parts Catalog Fig 45. FUEL PIPE 54 26 1 4
3GM30, 3GM30B, 3GM30C, 3GM30VE 3GM30 Parts Catalog Fig 49. FUEL LINE 58 17 1 4
3GM30, 3GM30B, 3GM30C, 3GM30VE 3GM30 Parts Catalog Fig 49. FUEL LINE 58 18 1 2
3GM30F, 3GM30FVE 3GM30 Parts Catalog Fig 50. FUEL LINE(3GM30F/FVE) 59 16 1 4
3GM30F, 3GM30FVE 3GM30 Parts Catalog Fig 50. FUEL LINE(3GM30F/FVE) 59 17 1 2
3GM30, 3GM30-YEU, 3GM30C-YEU, 3GM30F-YEU, 3GM30FC-YEU 3GM30-YEU Parts Catalog Fig 84. GASKET SET(OPTIONAL) 94 23 2 20
3GM30, 3GM30B, 3GM30C, 3GM30F, 3GM30FVE, 3GM30VE 3GM30 Parts Catalog Fig 91. GASKET SET(OPTIONAL) 100 23 2 20
3HM35C 3HM35 Parts Catalog Fig 48. FUEL LINES 49 15 1 2
3HM35C 3HM35 Parts Catalog Fig 48. FUEL LINES 49 16 1 4
3HM35F 3HM35 Parts Catalog Fig 49. FUEL LINES 50 15 1 2
3HM35F 3HM35 Parts Catalog Fig 49. FUEL LINES 50 16 1 4
3HM35C, 3HM35F 3HM35 Parts Catalog Fig 87. GASKET SET 88 20 2 20
3JH2, 3JH2Z 3JH2 Parts Catalog Fig 22. FUEL PIPE 26 7 1 5
3JH2, 3JH2-TE 3JH2-TE yanmarshop parts.csv Fig 22. FUEL PIPE 1 7 1
3JH2, 3JH2Z 3JH2 Parts Catalog Fig 22. FUEL PIPE 26 25 1 2
3JH2, 3JH2-TE 3JH2-TE yanmarshop parts.csv Fig 22. FUEL PIPE 1 25 1
3JH3CE, 3JH3E, 3JH3E(EPA) 3JH3E Parts Catalog Fig 29. FUEL PIPE & FUEL STRAINER 33 14 1 5
3JH3CE, 3JH3E, 3JH3E(EPA) 3JH3E Parts Catalog (2) Fig 29. FUEL PIPE & FUEL STRAINER 37 14 1 5
3JH3CE, 3JH3E, 3JH3E(EPA) 3JH3E Parts Catalog Fig 29. FUEL PIPE & FUEL STRAINER 33 34 1 2
3JH3CE, 3JH3E, 3JH3E(EPA) 3JH3E Parts Catalog (2) Fig 29. FUEL PIPE & FUEL STRAINER 37 34 1 2
3JH40 3JH40 Parts Catalog Fig 41. ALTERNATOR KIT(2ND)(OPTIONAL) 45 19 2 2
3JH40 3JH40 Parts Catalog Fig 42. ALTERNATOR KIT(2ND)(ISOLATED TYPE)(OPTIONAL) 46 20 2 2
3QM 3QM30 Parts Catalog Fig 1. CYLINDER BLOCK 2 6 2 1
3QM 3QM30 Parts Catalog Fig 1. CYLINDER BLOCK 2 6-1 ▲ 2
3QM 3QM30 Parts Catalog Fig 15. FUEL SYSTEM 27 60 1 2
3QM 3QM30 Parts Catalog Fig 15. FUEL SYSTEM 27 64 1
3QM 3QM30 Parts Catalog Fig 27. PACKING KIT(OPTIONAL) 47 45 2 20
3QM 3QM30 Parts Catalog Fig 34. CLUTCH KH-18A(FOR 3QM30)(OPTIONAL) 56 30 2
4JH, 4JH-DTE 4JH-DTE Parts Catalog Fig 1. CYLINDER BLOCK 6 13 2 1
4JH, 4JH-HTE 4JH-HTE Parts Catalog Fig 1. CYLINDER BLOCK 4 13 2 1
4JH, 4JH-HT, 4JH-T 4JH 4JH-T 4JH-HT Parts Catalog Fig 34. FUEL LINE 47 46 1 1
4JH, 4JH-HT, 4JH-T 4JH 4JH-T 4JH-HT Parts Catalog Fig 34. FUEL LINE 47 55-1 ▲ 1 2
4JH, 4JH-DTE 4JH-DTE Parts Catalog Fig 42. FUEL PIPE 48 6 1 5
4JH, 4JH-HTE 4JH-HTE Parts Catalog Fig 42. FUEL LINES 40 6 1 5
4JH2-DTE, 4JH2-HTE, 4JH2-TE, 4JH2-UTE(B), 4JH2E 4JH2 Parts Catalog Fig 1. CYLINDER BLOCK 9 12 2 1
4JH2-DTE, 4JH2-HTE, 4JH2-TE, 4JH2E 4JH2 Parts Catalog Fig 35. FUEL PIPE(4JH2-E,TE,HTE,DTE) 48 7 1 5
4JH2-DTE, 4JH2-HTE, 4JH2-TE, 4JH2E 4JH2 Parts Catalog Fig 35. FUEL PIPE(4JH2-E,TE,HTE,DTE) 48 25 1 2
4JH2-UTE(B) 4JH2 Parts Catalog Fig 36. FUEL PIPE(4JH2-UTE) 49 17 1 1
4JH2-UTE(B) 4JH2 Parts Catalog Fig 36. FUEL PIPE(4JH2-UTE) 49 23 1 2
4JH2-DTE, 4JH2-HTE, 4JH2-TE, 4JH2-UTE(B), 4JH2E 4JH2E Parts Catalog Fig 1. CYLINDER BLOCK 9 12 2 1
4JH2-DTE, 4JH2-HTE, 4JH2-TE, 4JH2E 4JH2E Parts Catalog Fig 35. FUEL PIPE(4JH2-E,TE,HTE,DTE) 48 7 1 5
4JH2-DTE, 4JH2-HTE, 4JH2-TE, 4JH2E 4JH2E Parts Catalog Fig 35. FUEL PIPE(4JH2-E,TE,HTE,DTE) 48 25 1 2
4JH2-UTE(B) 4JH2E Parts Catalog Fig 36. FUEL PIPE(4JH2-UTE) 49 17 1 1
4JH2-UTE(B) 4JH2E Parts Catalog Fig 36. FUEL PIPE(4JH2-UTE) 49 23 1 2
4JH3-DTE, 4JH3-HTE 4JH3-HTE-DTE Parts Catalog Fig 1. CYLINDER BLOCK 2 41 1 1
4JH3-DTE, 4JH3-HTE 4JH3-HTE-DTE Parts Catalog Fig 31. FUEL PIPE 33 16 1 1
4JH3-DTE, 4JH3-HTE 4JH3-HTE-DTE Parts Catalog Fig 31. FUEL PIPE 33 23 1 2
4JH3-TBE, 4JH3-TE 4JH3E Parts Catalog Fig 2. CYLINDER BLOCK(4JH3-TE) 3 41 1 1
4JH3CE, 4JH3E 4JH3E Parts Catalog Fig 41. FUEL PIPE(4JH3E) 48 14 1 5
4JH3CE, 4JH3CE1, 4JH3E 4JH3E Parts Catalog Fig 41. FUEL PIPE(4JH3E) 48 34 1 2
4JH3-TBE, 4JH3-TE 4JH3E Parts Catalog Fig 42. FUEL PIPE(4JH3-TE) 50 16 1 1
4JH3-TBE, 4JH3-TE 4JH3E Parts Catalog Fig 42. FUEL PIPE(4JH3-TE) 50 23 1 2
4JH45, 4JH57 4JH45-4JH57 Parts Catalog Fig 32. FUEL FILTER 40 18 1 2
4JH45, 4JH57 4JH45-4JH57 Parts Catalog Fig 39. ALTERNATOR KIT(2ND)(OPTIONAL) 49 29 2 2
4JH45, 4JH57 4JH45-4JH57 Parts Catalog Fig 60. (39A)ALTERNATOR KIT(2ND)(ISOLATED TYPE)(OPTIONAL) 50 20 2 2
4JH110, 4JH80 4JH80-4JH110 Parts Catalog Fig 41. FUEL FILTER 48 18 1 2
4JH110, 4JH80 4JH80-4JH110 Parts Catalog Fig 48. ALTERNATOR KIT(2ND)(OPTIONAL) 57 29 2 2
4JH110, 4JH80 4JH80-4JH110 Parts Catalog Fig 70. (48A)ALTERNATOR KIT(2ND)(ISOLATED TYPE)(OPTIONAL) 58 20 2 2
4JH-TE, 4JHE 4JHE-4JH-TE Parts Catalog Fig 1. CYLINDER BLOCK 6 13 2 1
4JH-TE, 4JHE 4JHE-4JH-TE Parts Catalog Fig 52. FUEL PIPE 58 6 1 5
4JH-TE, 4JHE 4JHE-4JH-TE Parts Catalog Fig 53. FUEL RETURN PIPE 59 2-1 ▲ 1 2
4LH-DTE, 4LH-HTE 4LH Parts Catalog Fig 25. AIR DUCT 38 18 1 1
4LH-STE 4LH Parts Catalog Fig 26. AIR DUCT(4LH-STE) 39 22 1 2
4LHA-DTE(P), 4LHA-DTZE(P), 4LHA-HTE(P), 4LHA-HTZE(P), 4LHA-STE(P), 4LHA-STZE(P) 4LHA Parts Catalog Fig 12. SUCTION MANIFOLD 19 3 1 1 / 2
4LHA-DTE(P), 4LHA-DTZE(P), 4LHA-STE(P), 4LHA-STZE(P) 4LHA Parts Catalog Fig 12. SUCTION MANIFOLD 19 14 1 2
4LHA-DTE(P), 4LHA-DTZE(P), 4LHA-HTE(P), 4LHA-HTZE(P), 4LHA-STE(P), 4LHA-STZE(P) 4LHA Parts Catalog Fig 63. SENSOR MOUNT 83 12 1 5
4LV150, 4LV170, 4LV195, 4LV230, 4LV250 4LV Parts Catalog Fig 64. ELECTRONIC TROLLING(TYPE-C/OPTIONAL) 82 42 3 1
4LV150, 4LV170, 4LV195, 4LV230, 4LV250 4LV Parts Catalog Fig 64. ELECTRONIC TROLLING(TYPE-C/OPTIONAL) 82 71 3 1
6LPA-STP2, 6LPA-STZP2, 6LPA-STZP3 6LPA Parts Catalog Fig 25. LUB. OIL PIPE(TURBINE) 32 9 1 2
6LP-DTE, 6LP-DTZE, 6LP-DTZEP1, 6LP-STE, 6LP-STZE, 6LP-STZEP1 6LP Parts Catalog Fig 29. LUB. OIL PIPE(TURBINE) 36 9 1 2
6LPA-STP2, 6LPA-STZP2, 6LPA-STZP3 6LPA Parts Catalog Fig 56. SENSOR MOUNT 64 16 1 7
6LP-DTE, 6LP-DTZE, 6LP-DTZEP1, 6LP-STE, 6LP-STZE, 6LP-STZEP1 6LP Parts Catalog Fig 63. SENSOR MOUNT 71 16 1 7
