Home › Part 23414-100000

23414-100000 Marine + Industrial

GASKET, 10X1.0

23414-100000 — Affiliate Parts Search

AmazoneBayAliExpress

As an Amazon Associate I earn from qualifying purchases. Other links (eBay, AliExpress) are also affiliate links — they help pay for the site, at no extra cost to you. More

Fitted to

Engines, drives and generators whose parts catalogue lists this part. Open any for its exploded parts list.

Engines
3TN75E-G1 24hp3TN75E-G2 24hp3TN82E-G1 33hp3TN82E-G2 33hp3TN84L-RTBZ 33hp3TNE84-G1A3TNE84-G2A3TNE84-SA3TNE84C-G1A3TNE84T-EMP4TN82E-G1 38hp4TN82E-G2 38hp4TNE106-G1A4TNE106-SA4TNE106T-G1A4TNE106T-SA4TNE84-G2A014TNE88-PG4TNV84T-DSA4TNV84T-DSA24TNV84T-DSA34TNV84T-GGE1GM 7.5hp1GM10 9hp1GM10C 9hp3GM30 27hp3GM30-YEU 27hp3GM30B 27hp3GM30C 27hp3GM30C-YEU 27hp3GM30F 27hp3GM30F-YEU 27hp3GM30FC-YEU 27hp3GM30FVE 27hp3GM30VE 27hp3HM35C 34hp3HM35F 34hp3JH2 38hp3JH2-TE 47hp3JH2Z 38hp3JH3CE 40hp3JH3E 40hp3JH3E(EPA) 40hp3JH40 40hp3QM 30hp4JH 44hp4JH-DTE 77hp4JH-HT 66hp4JH-HTE 75hp4JH-T 55hp4JH-TE 50hp4JH110 110hp4JH2-DTE 88hp4JH2-HTE 75hp4JH2-TE 62hp4JH2-UTE(B) 100hp4JH2E 50hp4JH3-DTE 125hp4JH3-HTE 100hp4JH3-TBE 75hp4JH3-TCE 75hp4JH3-TE 75hp4JH3CE 56hp4JH3CE1 56hp4JH3E 56hp4JH4-HTE 110hp4JH4-TE 75hp4JH45 45hp4JH4AE 55hp4JH4E 55hp4JH57 57hp4JH5E 53.8hp4JH80 80hp4JHE 44hp4LH-DTE 170hp4LH-HTE 140hp4LH-STE 230hp4LHA-DTE(P) 200hp4LHA-DTZE(P) 200hp4LHA-HTE(P) 160hp4LHA-HTZE(P) 160hp4LHA-STE(P) 240hp4LHA-STZE(P) 240hp4LV150 150hp4LV170 170hp4LV195 195hp4LV230 230hp4LV250 250hp6LP-DTE 250hp6LP-DTZE 250hp6LP-DTZEP1 250hp6LP-STE 300hp6LP-STZE 300hp6LP-STZEP1 300hp6LPA-STP2 315hp6LPA-STZP2 315hp6LPA-STZP3 315hp
Saildrives & gearboxes
KM35PKM35P1

OEM interchange

Other OEM part numbers for the same part — order from any of these makers or their dealers.

23414-100014

Aftermarket equivalents cross-ref

Third-party equivalents (Jabsco, Sierra, WIX, Mann…) — not OEM; verify before ordering. Usually cheaper than the marine dealer.

Equivalent P/NBrandDescriptionSourceConfidence
DIN 7603 10x1.0 DIN 7603 / Cu copper sealing washer ID 10 x 1.0mm - Yanmar 'GASKET; 10X1.0' = copper washer ID 10mm x 1.0mm thick; DIN 7603 mcmaster.com confirmed

Used in 101 places

Every catalog figure this part is placed in, the model(s) it applies to, and its reference/level/quantity.

Model(s)CatalogFigurePageRefLevQty
KM35P KM35 Parts Catalog Fig 6. CLUTCH HOUSING 14 22 1 1
KM35P1 KM35 Parts Catalog Fig 11. CLUTCH HOUSING 19 22 1 1
3TN75E-G1, 3TN75E-G2, 3TN82E-G1, 3TN82E-G2, 4TN82E-G1, 4TN82E-G2 3TN82E Parts Catalog Fig 21. LUB.OIL SYSTEM 29 56 1 2
3TN84L-RTBZ 3TN84L Parts Catalog Fig 9. LUB. OIL SYSTEM 13 21 1 2
3TNE84-G1A, 3TNE84-G2A, 3TNE84-SA, 3TNE84C-G1A 3TNE84 Parts Catalog Fig 10. LUB.OIL SYSTEM 15 16 1 2
3TNE84-G2A 3TNE84 Parts Catalog Fig 10. LUB.OIL SYSTEM 15 46 2 1
3TNE84-G1A, 3TNE84-G2A, 3TNE84-SA, 3TNE84C-G1A 3TNE84 Parts Catalog Fig 22. GASKET SET 37 30 2 2
3TNE84T-EMP 3TNE84T-EMP Parts Catalog Fig 10. LUB.OIL SYSTEM (A)=3TNE84T-EMP 14 38 2 1
3TNE84T-EMP 3TNE84T-EMP Parts Catalog Fig 11. LUB.OIL LINE (A)=3TNE84T-EMP 15 14 1 2
3TNE84T-EMP 3TNE84T-EMP Parts Catalog Fig 19. GASKET SET (A)=3TNE84T-EMP 24 25 2 2
4TNE106-G1A, 4TNE106-SA, 4TNE106T-G1A, 4TNE106T-SA 4TNE106-G1A-SA Parts Catalog Fig 10. LUB.OIL LINE 1 7 1
4TNE106-G1A, 4TNE106-SA, 4TNE106T-G1A, 4TNE106T-SA 4TNE106-G1A-SA Parts Catalog Fig 16. STARTER 1 101 1
4TNE84-G2A01 4TNE84 Parts Catalog Fig 10. LUB.OIL SYSTEM (A)=4TNE84-SA 14 53 2 1
4TNE88-PG 4TNE88-PG Parts Catalog Fig 9. LUB.OIL SYSTEM (A)=4TNE88-PG 13 36 1 2
4TNE88-PG 4TNE88-PG Parts Catalog Fig 18. GASKET SET (A)=4TNE88-PG 23 21 2 2
4TNV84T-DSA, 4TNV84T-DSA2, 4TNV84T-DSA3, 4TNV84T-GGE 4TNV84T Parts Catalog Fig 12. LUB. OIL PIPE (A)=4TNV84T-DSA 16 27 1 2
4TNV84T-DSA, 4TNV84T-DSA2, 4TNV84T-DSA3, 4TNV84T-GGE 4TNV84T Parts Catalog Fig 22. GASKET SET (A)=4TNV84T-DSA 26 29 2 2
1GM 1GM 2GM 3GM 3HM Parts Catalog Fig 25. LUB. OIL PIPE 35 10 1 2
1GM 1GM 2GM 3GM 3HM Parts Catalog Fig 65. GASKET KIT(OPTIONAL) 78 41 2 5
1GM 1GM 2GM 3GM 3HM Parts Catalog Fig 66. CLUTCH HOUSING 80 22 1 1
1GM 1GM 2GM 3GM 3HM Parts Catalog Fig 69. CONTROL DEVICE 83 8 1 1
1GM10, 1GM10C 1GM10 Parts Catalog Fig 85. GASKET SET(OPTIONAL) 92 13 2 5
1GM10 1GM10 Parts Catalog Fig 86. CLUTCH HOUSING 93 20 1 1
1GM10 1GM10 Parts Catalog Fig 89. REMOTE CONTROL DEVICE 96 8 1 1
1GM10 1GM10 Parts Catalog Fig 91. CLUTCH HOUSING 98 16 1 1
1GM10 1GM10 Parts Catalog Fig 96. CLUTCH HOUSING 103 10 1 1
1GM10 1GM10 Parts Catalog Fig 97. V-DRIVE HOUSING 104 12 1 1
3GM30, 3GM30-YEU, 3GM30C-YEU, 3GM30F-YEU, 3GM30FC-YEU 3GM30-YEU Parts Catalog Fig 29. LUB. OIL PIPE 38 13 1 2
3GM30, 3GM30B, 3GM30C, 3GM30F, 3GM30FVE, 3GM30VE 3GM30 Parts Catalog Fig 31. LUB. OIL LINE 40 13 1 2
3GM30, 3GM30-YEU, 3GM30C-YEU, 3GM30F-YEU, 3GM30FC-YEU 3GM30-YEU Parts Catalog Fig 84. GASKET SET(OPTIONAL) 94 22 2 5
3GM30, 3GM30B, 3GM30C, 3GM30F, 3GM30FVE, 3GM30VE 3GM30 Parts Catalog Fig 91. GASKET SET(OPTIONAL) 100 22 2 5
3GM30 3GM30 Parts Catalog Fig 92. CLUTCH HOUSING 101 16 1 1
3GM30 3GM30 Parts Catalog Fig 95. REMOTE CONTROL DEVICE 104 8 1 1
3GM30 3GM30 Parts Catalog Fig 97. CLUTCH HOUSING 106 16 1 1
3GM30 3GM30 Parts Catalog Fig 102. CLUTCH HOUSING 111 10 1 1
3GM30 3GM30 Parts Catalog Fig 103. V-DRIVE HOUSING 112 12 1 1
3HM35C, 3HM35F 3HM35 Parts Catalog Fig 32. LUB.OIL LINES 33 13 1 2
3HM35C, 3HM35F 3HM35 Parts Catalog Fig 87. GASKET SET 88 19 2 5
3JH2, 3JH2Z 3JH2 Parts Catalog Fig 14. LUB. OIL PIPE 17 10 1 2
3JH2, 3JH2-TE 3JH2-TE yanmarshop parts.csv Fig 14. LUB. OIL PIPE 1 23 1
3JH3CE, 3JH3E, 3JH3E(EPA) 3JH3E Parts Catalog Fig 14. LUB.OIL SYSTEM 15 29 2 1
3JH3CE, 3JH3E, 3JH3E(EPA) 3JH3E Parts Catalog (2) Fig 14. LUB.OIL SYSTEM 19 29 2 1
3JH3CE, 3JH3E, 3JH3E(EPA) 3JH3E Parts Catalog Fig 15. LUB.OIL PIPE 16 9 1 2
3JH3CE, 3JH3E, 3JH3E(EPA) 3JH3E Parts Catalog (2) Fig 15. LUB.OIL PIPE 20 9 1 2
3JH40 3JH40 Parts Catalog Fig 31. FUEL FILTER 35 18 1 1
3QM 3QM30 Parts Catalog Fig 8. LUB.OIL SYSTEM 16 30 1 2
3QM 3QM30 Parts Catalog Fig 22. CLUTCH HOUSING 39 11 2 1
3QM 3QM30 Parts Catalog Fig 27. PACKING KIT(OPTIONAL) 47 44 2 5
4JH 4JH 4JH-T 4JH-HT Parts Catalog Fig 10. SUCTION MANIFOLD 16 16 1 1
4JH-T 4JH 4JH-T 4JH-HT Parts Catalog Fig 11. SUCTION MANIFOLD 17 19 1 1
4JH-HT 4JH 4JH-T 4JH-HT Parts Catalog Fig 12. SUCTION MANIFOLD 18 16 1 4
4JH-HT 4JH 4JH-T 4JH-HT Parts Catalog Fig 12. SUCTION MANIFOLD 18 18 1 1
4JH, 4JH-HT, 4JH-T 4JH 4JH-T 4JH-HT Parts Catalog Fig 23. LUB. OIL PIPE 31 26 1 6
4JH, 4JH-DTE 4JH-DTE Parts Catalog Fig 28. LUB.OIL PIPE 33 23 1 6
4JH, 4JH-HTE 4JH-HTE Parts Catalog Fig 28. LUB. OIL LINES 24 23 1 6
4JH2E 4JH2 Parts Catalog Fig 9. SUCTION MANIFOLD(4JH2E) 18 15 1 1
4JH2-TE 4JH2 Parts Catalog Fig 10. SUCTION MANIFOLD(4JH2-TE) 19 19 1 4
4JH2-DTE, 4JH2-HTE, 4JH2-UTE(B) 4JH2 Parts Catalog Fig 11. SUCTION MANIFOLD(4JH2-HTE,DTE,UTE) 20 11 1 4 / 1
4JH2-DTE, 4JH2-HTE, 4JH2-TE, 4JH2-UTE(B), 4JH2E 4JH2 Parts Catalog Fig 21. LUB. OIL LINE 31 29 1 2 / 6 / 4
4JH2E 4JH2 Parts Catalog Fig 88. CLUTCH HOUSING 96 16 1 1
4JH2E 4JH2E Parts Catalog Fig 9. SUCTION MANIFOLD(4JH2E) 18 15 1 1
4JH2-TE 4JH2E Parts Catalog Fig 10. SUCTION MANIFOLD(4JH2-TE) 19 19 1 4
4JH2-DTE, 4JH2-HTE, 4JH2-UTE(B) 4JH2E Parts Catalog Fig 11. SUCTION MANIFOLD(4JH2HT,DT,UTE 20 11 1 4 / 1
4JH2-DTE, 4JH2-HTE, 4JH2-TE, 4JH2-UTE(B), 4JH2E 4JH2E Parts Catalog Fig 21. LUB. OIL LINE 31 29 1 2 / 6 / 4
4JH2E 4JH2E Parts Catalog Fig 88. CLUTCH HOUSING 116 16 1 1
4JH3-DTE, 4JH3-HTE 4JH3-HTE-DTE Parts Catalog Fig 1. CYLINDER BLOCK 2 12 2 1
4JH3-DTE, 4JH3-HTE 4JH3-HTE-DTE Parts Catalog Fig 10. SUCTION MANIFOLD 11 6 1 1
4JH3-DTE, 4JH3-HTE 4JH3-HTE-DTE Parts Catalog Fig 18. LUB.OIL PIPE 19 19 1 4
4JH3-TBE, 4JH3-TCE, 4JH3-TE 4JH3E Parts Catalog Fig 2. CYLINDER BLOCK(4JH3-TE) 3 12 2 1
4JH3-TBE, 4JH3-TCE, 4JH3-TE, 4JH3CE, 4JH3CE1, 4JH3E 4JH3E Parts Catalog Fig 14. SUCTION MANIFOLD 15 6 1 1
4JH3CE, 4JH3CE1, 4JH3E 4JH3E Parts Catalog Fig 21. LUB.OIL COOLER(4JH3E) 22 22 1 2
4JH3-TBE, 4JH3-TCE, 4JH3-TE 4JH3E Parts Catalog Fig 23. LUB.OIL PIPE(4JH3-TE) 24 19 1 4
4JH4-HTE, 4JH4-TE 4JH4-TE-HTE Parts Catalog Fig 18. LUB.OIL PIPE 22 6 1 2
4JH4-HTE, 4JH4-TE 4JH4-TE-HTE Parts Catalog Fig 46. GASKET SET(OPTIONAL) 51 10 2 3
4JH45, 4JH57 4JH45-4JH57 Parts Catalog Fig 32. FUEL FILTER 40 17 1 1
4JH4AE 4JH4AE Parts Catalog Fig 9. SUCTION MANIFOLD 12 4 2 1
4JH4AE 4JH4AE Parts Catalog Fig 43. GASKET SET(OPTIONAL) 51 10 2 1
4JH4E 4JH4E Parts Catalog Fig 9. SUCTION MANIFOLD 12 4 2 1
4JH4E 4JH4E Parts Catalog Fig 45. GASKET SET(OPTIONAL) 51 10 2 1
4JH5E 4JH5E Parts Catalog Fig 9. SUCTION MANIFOLD 12 4 2 1
4JH5E 4JH5E Parts Catalog Fig 44. GASKET SET(OPTIONAL) 52 10 2 1
4JH110, 4JH80 4JH80-4JH110 Parts Catalog Fig 23. LUB. OIL PIPE 30 8 1 2
4JH110, 4JH80 4JH80-4JH110 Parts Catalog Fig 41. FUEL FILTER 48 17 1 1
4JHE 4JHE-4JH-TE Parts Catalog Fig 34. LUB.OIL PIPE 39 14 1 2
4JH-TE 4JHE-4JH-TE Parts Catalog Fig 35. LUB.OIL PIPE 40 24 1 6
4LH-STE 4LH Parts Catalog Fig 26. AIR DUCT(4LH-STE) 39 21 1 2
4LH-DTE, 4LH-STE 4LH Parts Catalog Fig 30. LUB. OIL COOLER 43 27 2 1
4LH-DTE, 4LH-HTE, 4LH-STE 4LH Parts Catalog Fig 34. LUB. OIL PIPE(TURBOCHARGER) 48 7 1 4
4LHA-DTE(P), 4LHA-DTZE(P), 4LHA-HTE(P), 4LHA-HTZE(P), 4LHA-STE(P), 4LHA-STZE(P) 4LHA Parts Catalog Fig 1. CYLINDER BLOCK 6 29 2 1
4LHA-DTE(P), 4LHA-DTZE(P), 4LHA-STE(P), 4LHA-STZE(P) 4LHA Parts Catalog Fig 12. SUCTION MANIFOLD 19 13 1 2
4LHA-DTE(P), 4LHA-DTZE(P), 4LHA-HTE(P), 4LHA-HTZE(P), 4LHA-STE(P), 4LHA-STZE(P) 4LHA Parts Catalog Fig 26. LUB.OIL PIPE(TURBOCHARGER) 35 6 1 4
4LHA-DTE(P), 4LHA-DTZE(P), 4LHA-HTE(P), 4LHA-HTZE(P), 4LHA-STE(P), 4LHA-STZE(P) 4LHA Parts Catalog Fig 63. SENSOR MOUNT 83 6 1 4
4LV150, 4LV170, 4LV195, 4LV230, 4LV250 4LV Parts Catalog Fig 15. EXHAUST MANIFOLD 26 10 1 1
4LV150, 4LV170, 4LV195, 4LV230, 4LV250 4LV Parts Catalog Fig 26. LUB. OIL FILTER 37 1 1 1
4LV150, 4LV170, 4LV195, 4LV230, 4LV250 4LV Parts Catalog Fig 27. LUB. OIL PIPE(TURBINE) 38 12 1 4
4LV150, 4LV170, 4LV195 4LV Parts Catalog Fig 68. (35A)COOLING PIPE(FRESH WATER) 47 6 1 2
4LV230, 4LV250 4LV Parts Catalog Fig 69. (35B)COOLING PIPE(FRESH WATER) 48 18 1 5
6LPA-STP2, 6LPA-STZP2, 6LPA-STZP3 6LPA Parts Catalog Fig 8. TURBINE 15 34 1 1
6LP-DTE, 6LP-DTZE, 6LP-DTZEP1, 6LP-STE, 6LP-STZE, 6LP-STZEP1 6LP Parts Catalog Fig 9. TURBINE 16 34 1 1
6LPA-STP2, 6LPA-STZP2, 6LPA-STZP3 6LPA Parts Catalog Fig 25. LUB. OIL PIPE(TURBINE) 32 8 1 2
6LP-DTE, 6LP-DTZE, 6LP-DTZEP1, 6LP-STE, 6LP-STZE, 6LP-STZEP1 6LP Parts Catalog Fig 29. LUB. OIL PIPE(TURBINE) 36 8 1 2
