MarineDieselXRef
Home › Part 129150-01881

129150-01881 Marine + Industrial

GASKET

129150-01881 — Affiliate Parts Search

AmazoneBayAliExpress

As an Amazon Associate I earn from qualifying purchases. Other links (eBay, AliExpress) are also affiliate links — they help pay for the site, at no extra cost to you. More

Fitted to

Engines, drives and generators whose parts catalogue lists this part. Open any for its exploded parts list.

Engines
3TNV84T-BKWM3JH2 38hp3JH2-TE 47hp3JH2Z 38hp3JH3CE 40hp3JH3E 40hp3JH3E(EPA) 40hp3JH40 40hp3JH4E 39hp3JH5E 38.5hp4JH 44hp4JH-DTE 77hp4JH-HT 66hp4JH-T 55hp4JH-TE 50hp4JH110 110hp4JH2-DTE 88hp4JH2-HTE 75hp4JH2-TE 62hp4JH2-UTE(B) 100hp4JH2E 50hp4JH3-DTE 125hp4JH3-HTE 100hp4JH3-TBE 75hp4JH3-TCE 75hp4JH3-TE 75hp4JH3CE 56hp4JH3CE1 56hp4JH3E 56hp4JH4-HTE 110hp4JH4-TE 75hp4JH45 45hp4JH4AE 55hp4JH4E 55hp4JH57 57hp4JH5E 53.8hp4JH80 80hp4JHE 44hp

Supersession

Superseded by
Part No.DescriptionCodeApplies
129C26-01890 GASKET, HO-P R A=*2012.06; A=*2012.06.; A=EXXXXX; A=EXXXXX; B=EXXXXX; A=EXXXXX; B=EXXXXX; C=EXXXXX; A=EXXXXX; B=EXXXXX; C=EXXXXX; D=EXXXXX; E=EXXXXX
Replaces (older)
Part No.DescriptionCodeApplies
129470-01880 GASKET, GEAR CASE R A=*1991.01; B=*1991.01; C=*1991.01; A=*1991.01; B=*1991.01; C=*1991.01; D=*1991.01; E=*1991.01; A=*1991.03; A=*1991.03; B=*1991.03; A=*1991.03; B=*1991.03; C=*1991.03; A=*1991.03; B=*1991.03; C=*1991.03; D=*1991.03; E=*1991.03
No cross-references recorded for this part yet.

Used in 57 places

Every catalog figure this part is placed in, the model(s) it applies to, and its reference/level/quantity.

Model(s)CatalogFigurePageRefLevQty
3TNV84T-BKWM 3TNV84T-BKWM Parts Catalog Fig 10. HYDRAULIC PUMP 14 1 1 1
3TNV84T-BKWM 3TNV84T-BKWM Parts Catalog Fig 20. GASKET SET 25 4 2 1
3JH2, 3JH2Z 3JH2 Parts Catalog Fig 2. GEAR HOUSING 5 22 1 1
3JH2, 3JH2-TE 3JH2-TE yanmarshop parts.csv Fig 7. BONNET 1 16 1
3JH2, 3JH2-TE 3JH2-TE yanmarshop parts.csv Fig 15. COOLING SEA WATER SYSTEM 1 17 1
3JH2, 3JH2Z 3JH2 Parts Catalog Fig 15. COOLING WATER SYSTEM(SEA WATER) 18 34 1 1
3JH2, 3JH2Z 3JH2 Parts Catalog Fig 39. GASKET SET(OPTIONAL) 45 6 2 1
3JH2, 3JH2-TE 3JH2-TE yanmarshop parts.csv Fig 40. GASKET SET(OPTIONAL) 1 6 1
3JH3CE, 3JH3E, 3JH3E(EPA) 3JH3E Parts Catalog Fig 2. GEAR HOUSING 3 7 1 1
3JH3CE, 3JH3E, 3JH3E(EPA) 3JH3E Parts Catalog (2) Fig 2. GEAR HOUSING 6 7 1 1
3JH3CE, 3JH3E, 3JH3E(EPA) 3JH3E Parts Catalog Fig 16. COOLING SEA WATER PUMP 17 25 1 1
3JH3CE, 3JH3E, 3JH3E(EPA) 3JH3E Parts Catalog (2) Fig 16. COOLING SEA WATER PUMP 21 22 1 1
3JH40 3JH40 Parts Catalog Fig 22. COOLING PUMP(SEA WATER) 26 2 1 1
3JH4E 3JH4E Parts Catalog Fig 16. COOLING SEA WATER PUMP 20 22 1 1
3JH4E 3JH4E Parts Catalog Fig 16. COOLING SEA WATER PUMP 20 26 1 1
3JH4E 3JH4E Parts Catalog Fig 17. COOLING SEA WATER PUMP(OPTIONAL) 21 22 1 1
3JH4E 3JH4E Parts Catalog Fig 17. COOLING SEA WATER PUMP(OPTIONAL) 21 26 1 1
3JH4E 3JH4E Parts Catalog Fig 43. GASKET SET(OPTIONAL) 49 17 2 2
3JH5E 3JH5E Parts Catalog Fig 16. COOLING SEA WATER PUMP 19 22 1 1
3JH5E 3JH5E Parts Catalog Fig 16. COOLING SEA WATER PUMP 19 26 1 1
3JH5E 3JH5E Parts Catalog Fig 16. COOLING SEA WATER PUMP 19 29 1 1
3JH5E 3JH5E Parts Catalog Fig 44. GASKET SET(OPTIONAL) 52 17 2 2
4JH, 4JH-DTE 4JH-DTE Parts Catalog Fig 2. GEARS HOUSING 7 12-2 ▲ 1 1
4JH, 4JH-HT, 4JH-T 4JH 4JH-T 4JH-HT Parts Catalog Fig 2. GEARS HOUSING 6 12-2 ▲ 1 1
4JH, 4JH-HT, 4JH-T 4JH 4JH-T 4JH-HT Parts Catalog Fig 24. COOLING SEA WATER PUMP 33 22-3 ▲ 1 1
4JH, 4JH-DTE 4JH-DTE Parts Catalog Fig 30. COOLING SEA WATER PUMP 35 17-2 ▲ 1 2
4JH, 4JH-DTE 4JH-DTE Parts Catalog Fig 78. GASKET SET 86 6-2 ▲ 2 2
4JH2-DTE, 4JH2-HTE, 4JH2-TE, 4JH2-UTE(B), 4JH2E 4JH2 Parts Catalog Fig 2. GEAR HOUSING 10 11-2 ▲ 1 1
4JH2-DTE, 4JH2-HTE, 4JH2-TE, 4JH2-UTE(B), 4JH2E 4JH2 Parts Catalog Fig 22. COOLING SEA WATER PUMP 32 17-2 ▲ 1 1
4JH2-DTE, 4JH2-HTE, 4JH2-TE, 4JH2-UTE(B), 4JH2E 4JH2 Parts Catalog Fig 62. GASKET SET 90 6-2 ▲ 2 1
4JH2-DTE, 4JH2-HTE, 4JH2-TE, 4JH2-UTE(B), 4JH2E 4JH2E Parts Catalog Fig 2. GEAR HOUSING 10 11-2 ▲ 1 1
4JH2-DTE, 4JH2-HTE, 4JH2-TE, 4JH2-UTE(B), 4JH2E 4JH2E Parts Catalog Fig 22. COOLING SEA WATER PUMP 32 17-2 ▲ 1 1
4JH3-DTE, 4JH3-HTE 4JH3-HTE-DTE Parts Catalog Fig 2. GEAR HOUSING 3 8 1 1
4JH3-DTE, 4JH3-HTE 4JH3-HTE-DTE Parts Catalog Fig 20. COOLING SEA WATER PUMP 21 25 1 1
4JH3CE, 4JH3CE1, 4JH3E 4JH3E Parts Catalog Fig 3. GEAR HOUSING(4JH3E) 4 7 1 1
4JH3-TBE, 4JH3-TCE, 4JH3-TE 4JH3E Parts Catalog Fig 4. GEAR HOUSING(4JH3-TE) 5 8 1 1
4JH3-TBE, 4JH3-TCE, 4JH3-TE, 4JH3CE, 4JH3CE1, 4JH3E 4JH3E Parts Catalog Fig 26. COOLING SEA WATER PUMP 27 25 1 1
4JH4-HTE, 4JH4-TE 4JH4-TE-HTE Parts Catalog Fig 19. COOLING SEA WATER PUMP 23 20 1 1
4JH4-HTE, 4JH4-TE 4JH4-TE-HTE Parts Catalog Fig 46. GASKET SET(OPTIONAL) 51 18 2 2
4JH45, 4JH57 4JH45-4JH57 Parts Catalog Fig 21. COOLING PUMP(SEA WATER) 28 2 1 1
4JH4AE 4JH4AE Parts Catalog Fig 16. COOLING SEA WATER PUMP 19 22 1 1
4JH4AE 4JH4AE Parts Catalog Fig 16. COOLING SEA WATER PUMP 19 26 1 1
4JH4AE 4JH4AE Parts Catalog Fig 16. COOLING SEA WATER PUMP 19 29 1 1
4JH4AE 4JH4AE Parts Catalog Fig 43. GASKET SET(OPTIONAL) 51 18 2 2
4JH4E 4JH4E Parts Catalog Fig 16. COOLING SEA WATER PUMP 19 22 1 1
4JH4E 4JH4E Parts Catalog Fig 16. COOLING SEA WATER PUMP 19 26 1 1
4JH4E 4JH4E Parts Catalog Fig 17. C.S.W.PUMP(OPTIONAL) 20 22 1 1
4JH4E 4JH4E Parts Catalog Fig 17. C.S.W.PUMP(OPTIONAL) 20 26 1 1
4JH4E 4JH4E Parts Catalog Fig 45. GASKET SET(OPTIONAL) 51 18 2 2
4JH5E 4JH5E Parts Catalog Fig 16. COOLING SEA WATER PUMP 19 22 1 1
4JH5E 4JH5E Parts Catalog Fig 16. COOLING SEA WATER PUMP 19 26 1 1
4JH5E 4JH5E Parts Catalog Fig 16. COOLING SEA WATER PUMP 19 29 1 1
4JH5E 4JH5E Parts Catalog Fig 44. GASKET SET(OPTIONAL) 52 18 2 2
4JH110, 4JH80 4JH80-4JH110 Parts Catalog Fig 25. COOLING PUMP(SEA WATER)(FRONT MOUNT SPEC.) 32 2 1 1
4JH110, 4JH80 4JH80-4JH110 Parts Catalog Fig 26. COOLING PUMP(SEA WATER)(REAR MOUNT SPEC.) 33 1 1 1
4JH-TE, 4JHE 4JHE-4JH-TE Parts Catalog Fig 37. COOLING SEA WATER PUMP 42 22-3 ▲ 1 1
4JH-TE, 4JHE 4JHE-4JH-TE Parts Catalog Fig 64. GASKET KIT 72 6-2 ▲ 2 1
